From Soggy Bills to Sustainable Sips: Building a Homestead Rainwater Harvesting System

For years, the relentless drum of rain on our roof was a bittersweet symphony. On one hand, it brought life to our garden, filled the pond, and painted the landscape in vibrant green. On the other, it meant an ever-climbing water bill, a nagging reminder of our dependence on a municipal system that felt increasingly disconnected from the natural cycles around us. We knew there had to be a better way, a way to harness the bounty of the sky and reclaim our water independence. That's when we decided to dive headfirst into building our own rainwater harvesting system.

And let me tell you, it's been a game-changer! Not only did we reduce our water bill by a whopping 40%, but we also gained a deeper appreciation for the precious resource that sustains our homestead. It wasn’t without its challenges, but the satisfaction of watching our system fill after a good rain is a reward in itself. If you're ready to ditch the dependence and embrace a more sustainable way of life, read on. I'm going to walk you through the step-by-step process of building a rainwater harvesting system that will transform your homestead, one drop at a time.

Why Harvest Rainwater? The Benefits for Your Homestead

Before we get into the nitty-gritty, let's talk about why rainwater harvesting is a must-have for any self-respecting homestead. Beyond the obvious financial savings, here's a breakdown of the key benefits:

• Reduced Water Bill: As I mentioned earlier, we slashed our bill by 40%. Depending on your location and water usage, you could see similar (or even greater!) savings.
• Water Independence: In times of drought or municipal water restrictions, having your own water source is invaluable. It provides peace of mind and ensures your garden and animals have the water they need.
• Environmentally Friendly: Rainwater is naturally soft and free of chemicals like chlorine and fluoride, making it ideal for irrigation and other non-potable uses. Reducing your reliance on municipal water also lessens the strain on local water resources.
• Healthier Plants: Plants thrive on rainwater! It's naturally slightly acidic and contains beneficial nutrients that promote healthy growth.
• Increased Property Value: A well-designed and implemented rainwater harvesting system can be a selling point for your homestead, demonstrating your commitment to sustainability.

Now that you're convinced, let's get building!

Materials List: Gathering Your Supplies

Here's a detailed list of everything you'll need for our DIY rainwater harvesting system. Keep in mind that costs can vary depending on the size of your system and the materials you choose.

• Rain Barrel/Tank: We opted for a 275-gallon IBC tote ($100-$200 used). You can also use multiple smaller rain barrels. Ensure it's food-grade if you plan to use the water for anything beyond irrigation.
• Guttering and Downspout Diverter: We used standard 5-inch K-style gutters and a Leaf Defier downspout diverter with a 2-inch outlet ($50-$75).
• 2-inch Flexible Hose: Enough to connect the downspout diverter to the rain barrel ($20).
• Spigot: A ¾-inch brass spigot for easy water access ($15).
• Hole Saw: A 2-inch hole saw for drilling the inlet hole in the rain barrel ($20).
• Drill: For drilling holes for the spigot and inlet.
• Teflon Tape: To seal threaded connections ($5).
• Screen/Filter: To prevent debris from entering the rain barrel. We used a fine mesh screen ($10).
• Optional: First Flush Diverter: This diverts the first few gallons of rainwater (which contain the most contaminants) away from your tank. You can DIY one with PVC pipes and a ball valve ($30-$50).
• Optional: Stand for Rain Barrel: Elevating the rain barrel improves water pressure. We built one from cinder blocks ($20).
• Measuring Tape, Level, and Basic Hand Tools: You likely already have these on hand.

Note: Prices are approximate and may vary based on location and supplier.

Step-by-Step Instructions: Building Your Rainwater Harvesting System

Follow these detailed steps, accompanied by helpful photos, to create your own rainwater harvesting masterpiece.

Step 1: Prepare the Rain Barrel

• Clean the Rain Barrel: If you're using a used IBC tote or rain barrel, thoroughly clean it with soap and water. Rinse it multiple times to remove any residue.


• Drill the Inlet Hole: Using the 2-inch hole saw, drill a hole near the top of the rain barrel. This is where the hose from the downspout diverter will connect.

• Install the Spigot: Drill a hole near the bottom of the rain barrel, large enough to accommodate the threaded shank of the spigot. Wrap Teflon tape around the threads of the spigot and screw it into the hole. Tighten securely.

Step 2: Install Gutters and Downspout Diverter

• Install Gutters (if needed): If your house doesn't already have gutters, install them according to the manufacturer's instructions. Ensure they are properly sloped to direct water towards the downspout.

• Install the Downspout Diverter: Cut the existing downspout to create space for the downspout diverter. Install the diverter according to the manufacturer's instructions. Make sure the outlet of the diverter is positioned to direct water towards the rain barrel.

Step 3: Connect the Rain Barrel to the Downspout Diverter

• Position the Rain Barrel: Place the rain barrel on its stand (if using) in a location that is easily accessible to the downspout diverter. Ensure the ground is level and stable.

• Connect the Hose: Connect one end of the 2-inch flexible hose to the outlet of the downspout diverter and the other end to the inlet hole on the rain barrel. Secure the connections with hose clamps if necessary.

Step 4: Install the Screen/Filter

• Create a Filter: Cut a piece of fine mesh screen slightly larger than the inlet hole on the rain barrel. Secure the screen over the hole using duct tape or a rubber band. This will prevent leaves and debris from entering the rain barrel.


Step 5: (Optional) Install a First Flush Diverter

• Build the Diverter: A simple first flush diverter can be made from PVC pipes and a ball valve. The idea is to capture the initial dirty water in a separate chamber before it enters the main rain barrel.

• Install the Diverter: Connect the diverter between the downspout diverter and the rain barrel. The ball valve allows you to drain the initial dirty water.

Step 6: Test Your System!

• Wait for Rain: This is the hardest part! Once it rains, observe your system to ensure it's functioning properly. Check for leaks and make any necessary adjustments.

• Monitor Water Quality: Regularly inspect the water in the rain barrel for clarity and odor. If the water becomes cloudy or smells foul, drain the barrel and clean it thoroughly.

Common Mistakes and Troubleshooting

Here are a few things we learned the hard way during our rainwater harvesting journey:

• Don't underestimate the weight of a full rain barrel: 275 gallons of water weighs over a ton! Make sure your stand is sturdy enough to support the weight. Cinder blocks are a great option.
• Clogged Gutters = Disaster: Regularly clean your gutters to prevent overflows and ensure efficient water collection. Leaf guards can also help.
• Algae Growth: If you live in a sunny area, algae can grow in your rain barrel. Using an opaque rain barrel or painting it a dark color can help prevent this. You can also add a small amount of chlorine bleach (follow recommended guidelines) to kill algae.
• Freezing Temperatures: In cold climates, water in the rain barrel can freeze and damage the barrel or pipes. Drain the system before the first freeze or insulate the rain barrel to prevent freezing.


The Sweet Taste of Self-Sufficiency

Building our rainwater harvesting system was more than just a DIY project; it was a step towards greater self-sufficiency and a deeper connection with the natural world. The feeling of watering our garden with water we harvested ourselves is incredibly rewarding. And the extra money in our pockets? That's just icing on the cake!

I encourage you to take the plunge and build your own rainwater harvesting system. It's a project that will benefit your homestead, your wallet, and the environment. Don't be afraid to get your hands dirty and experiment. Every homestead is unique, so tailor the system to your specific needs and resources.

Now it's your turn! Share your experiences, questions, and tips in the comments below. Let's build a community of rainwater harvesters and create a more sustainable future, one drop at a time!
