Conquer Water Woes: Build Your Own DIY Rain Barrel System for Garden Irrigation!

Are you tired of watching your precious garden wither during those inevitable summer droughts? Do you cringe every time you see your water bill, knowing most of that water is going straight into irrigating your plants? Here at Better Homes and Harvests, we've all been there. We understand the struggle of balancing a thriving garden with responsible water usage. But what if you could tap into a free, readily available resource that falls right from the sky? That's right, we're talking about rainwater!

In this step-by-step guide, we'll walk you through building your very own low-cost, high-impact DIY rain barrel system. This project is perfect for beginner to intermediate homesteaders looking to enhance their self-sufficiency and embrace a more sustainable lifestyle. Get ready to ditch the guilt and embrace the green – let's get building!

Why a Rain Barrel? The Benefits Are Pouring In!

Before we dive into the nitty-gritty, let’s recap why a rain barrel is a fantastic addition to any homestead:

• Water Conservation: Reduces your reliance on municipal water, saving you money and conserving a precious resource.
• Plant Health: Rainwater is naturally soft and free of chemicals like chlorine, which can be harmful to plants.
• Drought Resilience: Provides a reserve of water to keep your garden thriving during dry spells.
• Reduced Runoff: Helps prevent stormwater runoff, which can pollute local waterways.
• Empowerment: There's something incredibly satisfying about using a system you built yourself to nurture your garden!

Gathering Your Supplies: Keepin' it Budget-Friendly

The beauty of this project is that you can often source many of the materials for free or at a very low cost. Here's what you'll need:

Materials:

1. A Large Plastic Barrel (50-55 Gallons): Look for food-grade barrels (often blue) at local farms, food processing plants, or online marketplaces. Check Craigslist or Facebook Marketplace – you can often find them for free! Estimated Cost: $0 - $50
2. Spigot: A brass or durable plastic spigot with threads to screw into the barrel. Estimated Cost: $5 - $15
3. Bulkhead Fitting (optional but recommended): This creates a watertight seal for the spigot. If your spigot has a long enough threaded end, you can get away with just a rubber washer and some sealant. Estimated Cost: $3 - $10
4. Screen Mesh: To cover the inlet and prevent mosquitoes and debris from entering. Fiberglass window screen or hardware cloth works well. Estimated Cost: $5 - $10
5. Downspout Diverter: Directs rainwater from your gutter into the barrel. Many different styles are available. Estimated Cost: $15 - $40
6. Overflow Hose: A length of garden hose to direct excess water away from your foundation. Estimated Cost: $5 - $10 (or use an old hose!)
7. Gravel or Concrete Blocks: To elevate the barrel and provide gravity for watering. Estimated Cost: $0 - $20 (depending on what you have on hand)
8. Plumber's Tape (Teflon Tape): To seal threaded connections and prevent leaks. Estimated Cost: $2
9. Silicone Sealant (optional but recommended): To further seal around the spigot and bulkhead fitting. Make sure it's safe for potable water if you plan on using the water for anything other than watering plants. Estimated Cost: $5 - $10

Tools:

1. Drill: With various sized drill bits.
2. Hole Saw: The size needed for your spigot or bulkhead fitting (check the product specifications).
3. Utility Knife or Scissors: For cutting the screen mesh.
4. Wrench: To tighten the spigot and bulkhead fitting.
5. Measuring Tape
6. Safety Glasses
7. Gloves

Total Estimated Cost: $35 - $150 (depending on how resourceful you are!)

Step-by-Step Instructions: Let's Get Our Hands Dirty!

Step 1: Prepare the Barrel

• Thoroughly clean the inside of the barrel with soap and water. Rinse it several times to remove any residue.

Step 2: Install the Spigot

• Determine the location for your spigot near the bottom of the barrel.
• Use the hole saw to drill a hole slightly smaller than the diameter of your spigot or bulkhead fitting.
• If using a bulkhead fitting, insert it into the hole and tighten it according to the manufacturer's instructions.
• Wrap the threads of the spigot with plumber's tape.
• Screw the spigot into the bulkhead fitting (or directly into the barrel, if you're skipping the bulkhead) and tighten it securely with a wrench.
• Apply silicone sealant around the spigot where it meets the barrel for extra leak protection (optional).

Step 3: Create the Inlet Screen

• Cut a circular hole in the top of the barrel, large enough to accommodate the downspout diverter.
• Cut a piece of screen mesh slightly larger than the hole.
• Secure the screen mesh over the hole using tape, screws, or by sandwiching it between the barrel and the downspout diverter. This will keep out debris and prevent mosquitoes from breeding.

Step 4: Install the Downspout Diverter

• Cut your downspout to the height recommended by the downspout diverter instructions.
• Install the downspout diverter according to the manufacturer's instructions.
• Connect the diverter to the rain barrel using the provided hose or a custom connection.

Step 5: Create an Overflow

• Drill a hole near the top of the barrel for the overflow hose.
• Attach the overflow hose to the hole using a hose clamp or a threaded fitting.
• Direct the overflow hose away from your foundation to prevent water damage.

Step 6: Elevate the Barrel

• Place the gravel or concrete blocks on a level surface near your downspout.
• Position the rain barrel on top of the blocks. Elevating the barrel provides gravity for watering and makes it easier to access the spigot.

Step 7: Test and Refine

• Wait for the next rain and observe your system in action! Check for leaks and make any necessary adjustments.
• Make sure the overflow is working properly and directing water away from your foundation.

Things to Consider: Tailoring Your System to Your Needs

• Multiple Barrels: Connect multiple barrels together for increased water storage.
• Drip Irrigation: Attach a drip irrigation system to your rain barrel for efficient watering.
• Water Filtration: Install a filter to remove sediment and debris for cleaner water.
• Aesthetic Considerations: Decorate your rain barrel to blend in with your landscape. You can paint it, add trellises, or even disguise it as a planter.
• Winterizing: In colder climates, disconnect the rain barrel from the downspout in the winter to prevent freezing and damage. Empty the barrel and store it upside down.

Troubleshooting: Don't Let Hiccups Dampen Your Spirits!

• Leaky Spigot: Tighten the spigot and apply more plumber's tape or silicone sealant.
• Clogged Screen: Clean the screen regularly to remove debris.
• Mosquitoes: Ensure the screen is securely in place and that there are no gaps for mosquitoes to enter. You can also add mosquito dunks (Bacillus thuringiensis israelensis or Bti) to the water, which are safe for plants and humans but kill mosquito larvae.
• Slow Filling: Check the downspout diverter to ensure it's properly directing water into the barrel.

Unleash Your Inner Rain Harvester!

Congratulations! You've successfully built your own DIY rain barrel system. Now you can enjoy the benefits of free, clean rainwater for your garden, knowing you're doing your part for the environment.

We encourage you to share your own experiences, tips, and photos in the comments below. Have you tried a different type of rain barrel? What challenges did you encounter, and how did you overcome them? Let's learn from each other and build a community of sustainable homesteaders!

Don't forget to share this post with your friends and fellow gardeners using the hashtag #BHHDiyHomestead! Let's spread the word about the benefits of rainwater harvesting and inspire others to embrace self-sufficiency. Happy gardening!
